今天在干嘛
设置页面
MoMo Lv5
  2023-03-15 10:02:47   2023-03-28 09:54:45

概述

内容

设置页面动态生成

需求

  1. 展示的内容完全通过配置确定
  2. 设置项的值目前有开关，数值和枚举三种情况，预留未来扩展
  3. 设置项的描述支持标题和副标题，预留未来扩展
  4. 支持跳转二级页面
  5. 支持分组

预计周期

1～2周

过程

实现数据获取接口

配置接口类型

新建一个operation文件用来定义接口的入参和出参

com/danale/edge/usersdk/operation/GetDeviceSettingListOp.kt

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
package com.danale.edge.usersdk.operation

import com.danale.edge.foundation.log.Logger
import com.danale.edge.usersdk.jni.BaseJsonOperation
import com.danale.edge.usersdk.jni.BaseResponse
import com.google.gson.Gson
import com.google.gson.annotations.SerializedName


class GetDeviceSettingListOp (val param: Param, logger: Logger, gson: Gson) :
    BaseJsonOperation<GetDeviceSettingListOp.Response>(logger, gson) {

    // 这里是回调
    override fun unmarshallSerializedResponse(jsonOutput: String?): Response {
        val response = Response()
        val array = gson.fromJson(jsonOutput, Array<ResultBean>::class.java)
        response.list = array
        return response
    }

    // 传入数据
    override fun performOperation(context: CallbackContext) {
        context.nativeResponseCallback(0, 0, "", mockList)  // 在这里使用mock数据
    }

    // 入参
    class Param(
        @SerializedName("device_id") val deviceId: String,
        @SerializedName("device_type") val deviceType: Int,
    )

      // 出参
    class Response : BaseResponse() {

      // 返回一个Array
        var list: Array<ResultBean>? = null

        override fun toString(): String {
            return "Response(list=${list?.contentToString()})"
        }

    }

    class ResultBean {

        @SerializedName("name")
        val name: String? = null

        @SerializedName("items")
        val items: Array<Item>? = null

        override fun toString(): String {
            return "ResultBean(name=$name, items=$items)"
        }

    }

    class Item {

        @SerializedName("id")
        val id: String? = null

        @SerializedName("type")
        val type: String? = null

        @SerializedName("subId")
        val subId: String? = null

        override fun toString(): String {
            return "Item(id=$id, type=$type, subId=$subId)"
        }

    }



}

mock数据如下

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
[
    {
        "name": "text_basic_setting",
        "items": [
            {
                "id": "text_device_name",
                "type": "String"
            },
            {
                "id": "text_device_info",
                "type": "Fragment"
            },
            {
                "id": "text_service_net",
                "type": "Fragment"
            },
            {
                "id": "Synchronize",
                "subId": "SynchronizeDescribe",
                "type": "Boolean"
            }
        ]
    },
    {
        "name": "text_device_setting",
        "items": [
            {
                "id": "text_device_flip",
                "subId": "flipDescribe",
                "type": "Boolean"
            }
        ]
    }
]

接口定义和实现

在userSdk中定义接口路径

com/danale/edge/usersdk/usecase/UserSdkUseCase.kt

1
2
3
4
5
6
7
/**
 * 获取设备设置列表
 */
fun getDeviceSettingList(
    id: String,
    type: Int
): Single<GetDeviceSettingListOp.Response>

在userSdkImpl中实现

com/danale/edge/usersdk/usecase/UserSdkUseCaseImpl.kt

1
2
3
4
5
6
override fun getDeviceSettingList(
    id: String,
    type: Int
): Single<GetDeviceSettingListOp.Response> {
    return GetDeviceSettingListOp(GetDeviceSettingListOp.Param(id, type), logger, gsonInst)
}

数据获取

在viewModel中获取数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
/**
 * 获取设备设置列表
 */
private fun loadSettingList() {
  viewModelScope.launch {
    val list = withContext(Dispatchers.IO) {
      try {
        deviceId32?.let {
            logger.d(TAG, "loadSettingList, getDeviceSettingList")
            sdk.getDeviceSettingList(it, deviceTypeCode).await()
        }

      } catch (e: Exception) {
        toastError(e)
        null
      }
    }
  }
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
when (title) {
    "text_basic_setting" -> {
        add(Section().apply {
            setHeader(SectionHeaderItem(getString(R.string.text_setting_basic)))
            when (item.id) {
                "text_setting_basic_device_name" -> {
                    add(nameItem)
                }
                "text_setting_basic_device_info" -> {
                    add(
                        StatusItem(
                            getString(R.string.text_setting_basic_device_info),
                            actionId = ACTION_NAV_ID_DEVICE_INFO
                        )
                    )
                }
                "text_setting_basic_device_network" -> {
                    add(
                        StatusItem(
                            getString(R.string.text_setting_basic_device_network),
                            actionId = ACTION_NAV_ID_DEVICE_NETWORK
                        )
                    )
                }
                "Synchronize" -> {
                    add(
                        SwitchItem(
                            getString(R.string.text_allow_metered_sync),
                            subTitle = getString(R.string.text_allow_metered_sync_tip),
                            backgroundResId = R.drawable.bg_round_bottom,
                            showSeparator = false,
                            loadBlock = { item ->
                                val useMeteredData =
                                    preference.getAllowMeteredDataCompute()
                                logger.d(TAG, "load, useMeteredData, $useMeteredData")
                                (item as? SwitchItem)?.isChecked = useMeteredData
                            },
                            checkedListener = { button, isChecked ->
                                logger.d(
                                    TAG,
                                    "cellular sync change, $isChecked, $button"
                                )
                                preference.setAllowMeteredDataCompute(isChecked)
                            }
                        ))
                }
            }
        })

    }
    "text_setting_device" -> {
        add(Section().apply {
            setHeader(SectionHeaderItem(getString(R.string.text_setting_device)))
            when (item.id) {
                "text_setting_ipc_flip_state" -> {
                    add(
                        SwitchItem(
                            getString(R.string.text_setting_ipc_flip_state),
                            subTitle = getString(R.string.text_setting_ipc_flip_state_tip),
                            backgroundResId = R.drawable.bg_round_bottom,
                            showSeparator = false,
                            loadBlock = { item ->
                                logger.d(TAG, "loadBlock, flip, $item")
                                val state = deviceThingInfo?.run {
                                    performOnIOWithDefault(null) {
                                        sdk.getDeviceFlipStatusWithCache(this).await()
                                    }
                                } ?: DpFlipState.NORMAL
                                logger.d(TAG, "loadBlock, flip state, $state")
                                (item as? SwitchItem)?.isChecked =
                                    (state == DpFlipState.UP_SIDE_DOWN)
                            },
                            checkedListener = { button, isChecked ->
                                logger.d(
                                    TAG,
                                    "checkedListener, flip, $isChecked, $button"
                                )
                                val state =
                                    if (isChecked) DpFlipState.UP_SIDE_DOWN else DpFlipState.NORMAL
                                viewModelScope.launch {
                                    performOnIOWithDefault(null) {
                                        deviceThingInfo?.let {
                                            sdk.setDeviceFlipStatusWithCache(it, state)
                                                .await()
                                        }
                                    }
                                }
                            }
                        ))
                }

            }

        })
    }
}


com/danale/edge/appbiz/ApplicationBusinessModule.kt

1
2
3
4
5
6
7
@Module
@InstallIn(SingletonComponent::class)
interface ApplicationBusinessModule {
    @Binds
    @Singleton
    fun bindSettingItemFactory(impl: SettingItemFactory): SettingItemRepository
}

com/danale/edge/ui/devicecontrol/setting/SettingItemRepository.kt

1
2
3
4
package com.danale.edge.ui.devicecontrol.setting

interface SettingItemRepository {
}

com/danale/edge/ui/devicecontrol/setting/DeviceSettingListViewModel.kt

1
2
3
// 设置项map
@Inject
lateinit var settingItem: SettingItemFactory

com/danale/edge/ui/devicecontrol/setting/SettingItemFactory.kt

1
2
3
4
5
6
7
8
9
10
11
class SettingItemFactory @Inject constructor(
    private val preference: AppPrefRepository
) :SettingItemRepository {

    fun syncAction(item: BaseSettingItem<RecyclerGroupieItemSwitchBinding>): Boolean {
        val useMeteredData = preference.getAllowMeteredDataCompute()
        (item as? SwitchItem)?.isChecked = useMeteredData
        return useMeteredData
    }

}
